Mine Ventilation Blower

Mine Ventilation Blower:

DK series counter-rotating main ventilator is specially designed according to the needs of various non-coal mine ventilation, such as metallurgy, nonferrous metals, gold, chemicals, building materials and nuclear industry, etc, which can be used as main fan and auxiliary fan. It can be installed on the surface or in the underground, suitable for the combined operation of multiple fans, which is an ideal machine station ventilator of various machine stations in the ventilation system of the multi-fan series multi-stage machine station. It is also suitable for the ventilation in large workshops, tunnels, civil air defense projects, etc.

Mine Ventilation Blower

When used as the main fan and the station fan, the DK series counter-rotating main ventilator should be equipped with a special diffuser. The main fan on the surface shall be equipped with a diffuser to convert one part of the dynamic pressure into static pressure and reduce the dynamic pressure loss of the outlet, so as to achieve the purpose of energy saving. The ventilator installed in the well shall be equipped with a diffuser, which not only can reduce the local resistance coefficient, but also can reduce the dynamic pressure value of the diffuser outlet, thereby greatly reducing the local resistance of the fan device and saving ventilation power consumption.
